A slab trolley is a practical and efficient material handling solution designed for transporting concrete and other construction materials across slab surfaces in building sites. With a net load capacity of 500 kg or approximately 0.3 cubic meters, it is ideal for moving medium volumes of material to specific pouring locations without the need for manual carrying. The key feature of this trolley is its rotating bucket, which swivels a full 360 degrees around its axis for flexible material placement and can be tilted up to 90 degrees for quick and controlled unloading.

The slab trolley runs on rails made from 40 mm diameter pipe, specially designed with left and right bends to facilitate smooth directional changes during operation. It moves on robust cast iron heavy-duty wheels fitted with ball bearings, ensuring stability, low rolling resistance, and a long operational life even under continuous use.

Powered by a reliable 3 HP 3-phase brake motor, the trolley system uses an 8 mm wire rope to pull the loaded bucket across the slab with steady, controlled motion. Built for rugged site conditions, the slab trolley is a durable, low-maintenance option that significantly improves concreting speed and efficiency.
